SpeedBox 1.0 B.Tuning pentru Bosch (Smart System)

PROPERTIES:
Activation: SpeedBox App / function WALK / + – + –
Maximum speed: 50 km/ h
Indication of tuning activation/deactivation: YES (2,5/9,9 km/h)
Display shows:
readable actual speed
correct travelled distance (after the countdown process is
finished)
Compatible with:
displays KIOX 300
motors Bosch Gen4 + Smart System
SpeedBox App
Not compatible with e-bikes that have a magnet attached to a valve (Bosch Rim Magnet)

In case of updating the software of your e-bike, uninstall SpeedBox from the e-bike first, update the software and reinstall SpeedBox.

The tuning chip with Bluetooth technology and mobile app for your e-bike with Bosch Gen4 motor and Smart System. Enjoy your unlimited ride and all the great functions that our SpeedBox App has to offer.

SpeedBox B.Tuning brings a unique connection of e-bike and mobile phone and suppresses the speed limiter on your e-bike. When in use, the display shows the real speed up to 22.2 km/h. After exceeding this speed your actual speed is indicated on the last two digits of the display.

Example:

– 22.3 corresponds to a speed of 23 km/h

– 23.1 corresponds to a speed of 31 km/h

The actual speed and other riding data will be displayed correctly in our SpeedBox App – right on the display of your phone.

How does SpeedBox 1.0 B.Tuning work?

To activate all the functions of the SpeedBox correctly, it is necessary to enter the menu and switch to the circumference of your bike after switching on the e-bike.

This tuning chip is also very easy to control. You will activate SpeedBox 1.0 B.Tuning via mobile app or directly on your e-bike’s control unit by activating the WALK assist function shortly (holding down the “–” button). Your e-bike display will show a value of 9,9 km/h (6,2 mph) and from now on you will be able to ride at unlimited speed.

To deactivate the tuning chip, activate the WALK assist function shortly again (by holding down the “–” button). Your e-bike display will show a value of 2,5 km/h (1,6 mph) and the speed limit will be reset to 25 km/h. Your e-bike will then work the same as before the chip installation.

SpeedBox was also designed for e-bikes that do not have the WALK assist function enabled, or activated. In this case, you can activate/deactivate tuning by switching between two assistance modes twice, i.e. by pressing the +-+- buttons.

When you first open the SpeedBox App, you will be asked to type in a new PIN. This PIN will be requested each time you open the SpeedBox App. After confirming the PIN, you will be asked to set a service password. Your service password will be used in case you forget the PIN or want to change it.

The „countdown” process will continue concealed during charging, therefore, if you charge your e-bike with a connected battery, you can ignore the following instructions. If you need to remove the battery from your e-bike in order to charge it, you need to wait for the SpeedBox to carry out the „countdown” process after the ride. When you stop your e-bike, the ongoing „countdown” process will be indicated by the increasing riding time. Once the „countdown” process is completed, the riding time stops and the e-bike display shows the correct distance travelled. The countdown process can be interrupted by turning off the ebike or by setting off, so it does not restrict the use of your e-bike in any way. However, you still need to have the countdown process run regularly to prevent tuning detection.

SpeedBox App for SpeedBox B.Tuning

SpeedBox App is an application specially designed for SpeedBox B.Tuning, which uses Bluetooth technology to connect your e-bike to your mobile application. After downloading the application and connecting your mobile phone to your e-bike you will see current data and trip parameters displayed on your phone. Individual trips can be stored so that the results can be compared with friends and together they can monitor their performance. So just enjoy the ride and leave checking the parameters for later!

SpeedBox App features:

• Tuning control
• Speed limit setting
• Saving and viewing your trips
• Invisible mode
• Motor diagnostics

SpeedBox B.Tuning is not limited to working with SpeedBox App. However, it is a great tool that will provide you with a complete overview of your performances.

Download SpeedBox App to your phone just before ordering the SpeedBox B.Tuning chip. You can try out our demo version and get to know all the awesome features and, at the same time, make sure that the application is fully functional on your phone. To connect to the SpeedBox B.Tuning chip, your phone needs to be equipped with Bluetooth 4.0 or higher.
